The selection of a car lift type is based on the height of the vehicle's movement, the elevator space dimensions, and the price. Car lifts are considered essential equipment in many construction and industrial projects, specifically designed for transporting vehicles. These lifts are widely used not only in the parking areas of modern apartments but also in car showrooms, repair shops, and large warehouses. When choosing a suitable car lift, several factors need to be considered that ultimately affect its efficiency, safety, and price.
The useful load capacity of car lifts ranges from 2 to 10 tons. If the vehicle is carrying cargo, its weight must also be taken into account. Below are explanations of two types of car lifts:
This type of lift is ideal for low-rise buildings or those up to three floors.
Lift speed | 0.2m/s to 0.6 m/s |
Required power supply | 3-phase power |
Types of installation methods | Direct jack from below Indirect double-side jack |
Minimum capacity | 2500 kg |
Hydraulic lifts are implemented in two ways:
Direct jack from below: Suitable for projects with more space
Indirect double-side jack: Designed for more confined spaces
Considering the required height and project features, hydraulic lifts are an excellent choice. Owj Lift, with over 22 years of experience in the elevator industry, professionally designs and installs these systems, recommending them for buildings with a height of less than 10 meters.
This type of lift is designed for buildings with more than three floors. Unlike hydraulic systems, which have height limitations, traction lifts can be used in taller buildings. Higher speed and better performance in high-rise buildings are the advantages of this system.
Types of installation methods:
Gearless 2:1: For higher speed and efficiency.
Gearbox 4:1: Suitable for taller heights.
Owj Lift, with extensive experience in installing and providing these systems, has successfully completed major projects in various cities across Iran and even in neighboring countries like Oman, Iraq, and Armenia.
The type of **elevator system** and the car elevator capacity determine what? These two factors define the dimensions of the car elevator, which you can review in the table below.
Usable dimensions of car elevators | |||
Capacity in kilograms | 2000 | 2500 | |
Cabin dimensions (mm) | Width b1 | 2400 | 2500 |
Depth d1 | 5000 | 5700 | |
Height | 2200 | ||
Dimensions and type of doors (mm) | Width b2 | 2400 | 2500 |
Height h3 | 2200 | ||
Door type | Hinged-sliding | ||
Shaft dimensions (mm) | Width b3 | 3200 | 3300 |
Depth d2 | 5300 | 6000 | |
Pit depth d3 (mm) | - | 1300
| |
Height from the top floor to the shaft ceiling h1 (mm) | Electric elevators | 4200 | |
Hydraulic elevators | 3300 | ||
Room dimensions (mm) | Width b4 | 2000 | |
Height h2 | 2000 | ||
H2 height | 2000 | ||
Hydraulic elevator room dimensions | Width b4 | 3200 | |
Depth d4 | 5300 | 6000 | |
Height h2 | 2000 | ||
The choice of type and capacity of a car elevator depends on various factors, some of which are mentioned below:
Owj Lift, as one of the pioneers in the elevator industry in Iran and the region, guarantees that you will not only choose the best product but also enjoy exceptional support services through specialized consultation, a 5-year post-sale service, and 24-hour maintenance.
| Specialized Consultation | Owj Lift’s experienced sales team is ready to provide precise and professional advice on elevator selection and its components. |
| Free Inspection | Project visits and assessments are carried out free of charge. |
| Professional Design | Design of various traction and hydraulic car elevators tailored to your project needs. |
| Warranty and Post-Sale Service | A 5-year warranty along with 24-hour maintenance service. |
Owj Lift has completed successful projects in major cities like Mashhad, Tehran, Kish, and Qeshm, as well as extensive operations in neighboring countries such as Oman and Armenia.
Choosing the right car elevator has a direct impact on the efficiency, safety, and ease of use of your space. Based on capacity, speed, and system type, you need to make the best choice for your project. With over 22 years of experience in this industry, Owj Lift can assist you in making the best decision and provide you with professional services and consultation. Contact our experts at 0513103.
| MAX. LOAD | 450 Kg |
|---|---|
| MAX. TRAVEL | 30 |
| MAX. SPEED | 1.6 |
| Machine room | Located on the rooftop |
| Doors types | telescopic & central |
| Shaft dimensions | telescopic door (160*160) & central door (160*180) |
| MAX. cabin area | 130 m |
| Pit height | 150 cm |
| Overhead height | 3.9 |
| MAX. LOAD | 450 Kg |
|---|---|
| MAX. TRAVEL | 30 |
| MAX. SPEED | 1.6 m/s |
| Machine room | Located on the rooftop |
| Doors types | telescopic & central |
| Shaft dimensions | telescopic door (150*150) & central door (150*180) |
| MAX. cabin area | 130 m |
| Pit height | 150 cm |
| Overhead height | 3.9 |
| MAX. LOAD | 600Kg |
|---|---|
| MAX. TRAVEL | |
| MAX. SPEED | 1.6 m/s |
| Machine room | Located on the rooftop |
| Doors types | |
| Shaft dimensions | Telescopic Door (170*180) - Central Door (180*180) |
| MAX. cabin area | 1.66 m² |
| Pit height | 150 cm |
| Overhead height | 3.9 m |
| MAX. LOAD | 750kg |
|---|---|
| MAX. TRAVEL | 30 |
| MAX. SPEED | 1.6 m/s |
| Machine room | Located on the rooftop |
| Doors types | telescopic & central |
| Shaft dimensions | telescopic door (170*200) & central door (210*170) |
| MAX. cabin area | 2.00 m² |
| Pit height | 150 cm |
| Overhead height | 3.9 |
What do the type of elevator system and the capacity of the car elevator determine?
These two factors determine the dimensions of the car elevator.
Why choose Owj Lift for purchasing a car elevator?
Owj Lift, as one of the pioneers in the elevator industry in Iran and the region, ensures that you will not only select the best product but also receive exceptional support services, including specialized consultation, a 5-year after-sales service, and 24-hour maintenance.
On what basis is the type of car elevator chosen?
The selection of the car elevator type is based on the height of the vehicle's movement, the elevator space dimensions, and the price.
